Gear Immersible Ultrasonic Transducer 1800 Watt 0-30 Minutes Adjustable Timer

Skymen Technology Corporation Limited
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment

Gear Immersible Ultrasonic Transducer 1800 Watt 0-30 Minutes Adjustable Timer

  • 1
  • 2
  • 3

Brand Name : Skymen

Model Number : JP-1036I

Certification : SGS, FCC, CE, RoHS, ISO9001

Place of Origin : China

MOQ : 1 unit

Price : Negotiation

Payment Terms : T/T

Supply Ability : 8000 pcs per month

Delivery Time : In Stock

Packaging Details : 1unit per carton / wooden case

Model : JP-1036I

Box Size : 500X460X100mm

Transducers : 36pcs

Ultrasonic Power : 1800W

Timer : 0-30 minutes adjustable

Frequency : 28KHz / 40KHz

Material : SUS 304

G.W : 25KG

Power Supply : AC 110V ; AC 220V

Generator : 1 unit

Connected Cable : Rigid/flexible Tube

Generator size : 270*440*150

Contact Now

Immersible Ultrasonic Transducers Plate/Box

Features:

  • More convenient for operation
  • Stainless steel tank has resistance to wear and long work life.
  • Can be moved to any tank
  • Controlled by generator
  • Use just tab water, or industrial solvent cleaner for more higher cleaning requirement

JP-1006I product specification:

Model JP-1036I
Box Size 500X460X100mm
Transducers 36pcs
Ultrasonic Power 1800W
Frequency 28KHz / 40KHz
G.W 25KG

How to Use an Ultrasonic Cleaner for Medical & Surgical Instruments


Medical and surgical instruments in a variety of sizes and complexity can pose challenges when it comes to cleaning, disinfecting and sterilizing them after use. An ultrasonic cleaner is an ideal tool for the first step in this three step process to protect medical personnel and patients from possible infection due to pathogens that remain on the instruments after a procedure.

Suggested Ultrasonic Cleaning Procedure

In all cases manufacturers’ instructions should be followed when using an ultrasonic cleaning process. These are representative steps.

Fill the ultrasonic cleaning tank with an approved medical instrument cleaning solution such as CLN-LR012 available from Tovatech following dilution instructions provided. Turn the cleaner on to start the degassing process. This step removes entrained air in new solutions that interferes with the efficiency of cavitation and takes approximately 10 minutes.

In the meantime:

  • Segregate instruments by alloy or composition to avoid potential damage (Chromium plated instruments should not be cleaned ultrasonically)
  • Instruments with movable parts should be disassembled to facilitate cleaning
  • Place the instruments the ultrasonic cleaner’s mesh basket, taking care that they do not come in contact with each other
  • Cannulated or lumened instruments should be positioned to insure interiors are wetted with the cleaning solution. In some instances placing them on an angle will facilitate this
  • Set the control panel per manufacturers’ instructions and start the cleaning process

At the end of the cycle, remove the instruments from the ultrasonic cleaning bath and thoroughly rinse them to remove all traces of the cleaning solution. Deionized water rinses will avoid spotting. If the instruments are not to be immediately disinfected and sterilized be certain that they are thoroughly dried and protected. Part reassembly can occur after sterilization.

Procedures should be in place to guide the replacement of used ultrasonic cleaning solutions. In some instances it is recommended that solution be drained and tanks thoroughly cleaned and dried after each ultrasonic cleaning cycle. Most solutions available today are biodegradable, which facilitates disposal but local authorities should be consulted on proper practices.


The ultrasonic cleaner uses ultrasonic waves (vibration) using water with detergents or enzymatic products to break up soil and organic material on medical instruments/devices. These devices are rinsed then autoclaved (sterilized). The autoclave sterilizer uses heat, steam, and pressure to kill all pathogenic microorganisms and their spores.

Package Includes:
1 x Ultrasonic Transducers Plate
1 x Generator
1 x Manual

Clean effect:
